UltiMaker S7


Exc. GST

UltiMaker S7

A new level of 3D printing success.
We took everything our customers love about the award-winning UltiMaker S5… And made it even better. The S7 is packed full of our latest technology, making it easier than ever to 3D print high-quality parts.




UltiMaker S7

The Ultimaker S7 is a powerful and versatile 3D printer that can handle any project. Whether you need to print complex models, functional prototypes, or custom parts, the Ultimaker S7 can deliver high-quality results with speed and precision. The Ultimaker S7 features a large build volume, dual extrusion, swappable print cores, and advanced connectivity options. It also supports a wide range of materials, including engineering plastics, composites, and metal filaments.

Additional information


Build volume: 330 x 240 x 300 mm (13 x 9.4 x 11.8 inches)

Assembled dimensions: W 495 x D 585 x H 800 mm (W 19.5 x D 23 x H 31.5 inches)

Print technology: Fused Deposition Modelling (FDM)

Compatible filament diameter: 2.85 mm

Weight: 29.1 kg (64.2 lbs)

Maximum power output: 500 W

Layer resolution: 0.25 mm nozzle: 150 – 60 micron 0.4 mm nozzle: 200 –
20 micron 0.6 mm nozzle: 300 – 20 micron 0.8 mm nozzle: 600 – 20 micron

XYZ resolution: 6.9, 6.9, 2.5 micron

Feeder type: Dual-geared feeder, reinforced for composite materials

Display: 4.7-inch (11.9 cm) colour touchscreen

Print core replacement: Swappable print cores

Print head: Dual extrusion print head with an auto-nozzle lifting system,
swappable print cores, and flood detection.

Nozzle diameters: 0.25 mm, 0.4 mm, 0.6 mm, 0.8 mm

Filter technology: Replaceable EPA filter

Air extraction rate: 1 – 50 m³/h (35 m³/h nominal rate for most materials
at 23 °C)

Nozzle temperature: 180 – 280 °C

Nozzle heat-up time: < 2 minutes

Operating sound: < 51 dBA

Build plate levelling: Advanced active levelling with more accurate inductive

Build plate: PEI-coated flexible steel build plate

Build plate heat-up time: < 5 minutes (from 20 to 60 °C)

Operating ambient temperature: 15 – 32 °C (59 – 90 °F)

Non-operating temperature: 0 – 32 °C (32 – 90 °F)
