UltiMaker S3

Build volume: 230 x 190 x 200 mm (9 x 7.4 x 7.9 inches)

Assembled dimensions: W 394 x D 489 x H 637 mm
(W 15.5 x D 19.3 x H 25.1 inches)

Print technology: Fused Deposition Modelling (FDM)

Compatible filament diameter: 2.85 mm

Weight:14.4 kg (31.7 lbs)

Maximum power output: 350 W

Layer resolution: 0.25 mm nozzle: 150 – 60 micron
0.4 mm nozzle: 200 – 20 micron
0.6 mm nozzle: 300 – 20 micron
0.8 mm nozzle: 600 – 20 micron

XYZ resolution: 6.9, 6.9, 2.5 micron

Feeder type: Dual-geared feeder, reinforced for composite materials

Display: 4.7-inch (11.9 cm) colour touchscreen

Print core replacement: Swappable print cores

Print head: Dual extrusion print head with an auto-nozzle lifting system,
swappable print cores, and flood detection.

Nozzle diameters: 0.25 mm, 0.4 mm, 0.6 mm, 0.8 mm

Build speed: < 24 mm³/s

Nozzle temperature: 180 – 280 °C

Nozzle heat-up time: < 2 minutes

Operating sound: < 50 dBA

Build plate levelling: Advanced active levelling

Build plate: 20 – 140 °C heated glass build plate

Build plate heat-up time: < 4 minutes (from 20 to 60 °C)

Operating ambient temperature: 15 – 32 °C (59 – 90 °F)

Non-operating temperature: 0 – 32 °C (32 – 90 °F)
